XTR Slide Out Kit

Estimated Lead Time: 4-5 Weeks

The XTR Slide Out Kit allows you to mount a piece of Xtrusion on the inside of your bed rack, on either the side brace or top brace, providing you a slide out for your gear. These are used to mount accessories on the inside of your bed rack. Select your bed rack length below.

This concept uses linear bearings to create an inexpensive slide out mechanism for easy access to things such as Rotopax, Shovels, Propane tanks, etc.

What's Included:

• (1) Slide bar to the length to match your bed rack.
• (4-8) Linear Slide Bearings w/ Hardware - quantity depends on length of the slide.
• (1) End Cap.

• (1) Locking lever mechanism to go on a linear slide.

NOTES:

The full slide out is intended to be used on an XTR1 style rack (without a center upright). The center upright can interfere with proper operation of a full length slide out, so it is recommended to use a half length slide out for an XTR3 series rack.

When selecting a half length slide out, choose the full length of your rack. The slide length will be based on an XTR3 rack. For example, a 60" rack will include a 28.5" slide bar.





Slide Bar Length by rack length:

Rack Length	Slide Type	Slide Bar Length	Slide Type	Slide Bar Length
46	FULL	45.7	HALF	21.5
48	FULL	47.7	HALF	22.5
50	FULL	49.7	HALF	23.5
51	FULL	50.7	HALF	24
52	FULL	51.7	HALF	24.5
53	FULL	52.7	HALF	25
54	FULL	53.7	HALF	25.5
56	FULL	55.7	HALF	26.5
58	FULL	57.7	HALF	27.5
60	FULL	59.7	HALF	28.5
61	FULL	60.7	HALF	29
62	FULL	61.7	HALF	29.5
66	FULL	65.7	HALF	31.5
71	FULL	70.7	HALF	34
72	FULL	71.7	HALF	34.5
74.4	FULL	74.1	HALF	35.7
75	FULL	74.7	HALF	36
78	FULL	77.7	HALF	37.5
84	FULL	83.7	HALF	40.5
